ZC-QC212DW Toyota Electric Control Engine and Automatic Transmission Comprehensive Training Desk

【Product Introduction】

This engine training desk is based on Toyota 3S-FE original electro-injection gasoline engine and A140E automatic transmission, consisting of the main tables, console, and detection desk. It is suitable for the construction and maintenance training of the vehicle engine structure and maintenance training of medium and high -level vocational colleges and training institutions, which can meet the structure, working principles, fault settings and diagnosis of electronic control gasoline engines. This experimental equipment is convenient, safe, reliable, and easy to maintain.

[Composition of engine training desk structure]

Toyota 3S-FE original electric injection gasoline engine and A140E automatic transmission assembly, original car engine control computer, combined instrument, anti-theft computer, engine starting all related original car accessories, fault settings and exclusion systems, original vehicle circuit schematic diagrams Board and detecting terminals, 60AH large -capacity batteries, large -capacity stainless steel fuel tanks, engine acceleration mechanisms, control surface cabinets, mobile tables, table frame power switches, OBD diagnostic seats, heat dissipation systems, task -driven teaching modes training guidance books And table operation instructions.

Each sensor and actuator installation of digital display tables, table frame installation of fuel pressure gauges and vacuum meters, lock -locking universal foot wheels, stainless steel guards, high temperatures of the table frame, and rotation are installed.

[Function description of engine training desk]

1. Display function

2. Dynamic operation function

3. Real -time display function

4. Detection function

5. Signal simulation function

6. Self -diagnosis function

7. Anti -theft system settings function

8. Fault settings and assessment functions

9. Divided by the teaching content, the functional areas are clear and clear.

Panel process and characteristics

(1) Measurement panel

The panel has the characteristics of large temperature difference (-30 ~ 60 ° C), wear resistance, moisture-proof, corrosion resistance, not easy to deform, and long life.

a. Use 8mm thick high -quality high -density PVC board as the bottom plate.

b. Using imported high -quality, high -intensity and high sticky bottom membrane materials, German laser spraying technology is formed, color content has extremely high clarity, and the surface covers high -intensity protection film. It has the characteristics of abrasion resistance (more abrasion -resistant and scratch -resistant effects exceeds organic glass), moisture -proof, corrosion resistance (high -quality clearing agent corrosion), and not easy to retreat. (Non -spraying, aluminum -plastic panel UV or printing).

(2) Control panel

a. Use 5mm thick aluminum plastic panels, sturdy and durable, not easy to deform.

b. Using high -definition fonts, it never retreats. It has fire prevention, waterproof, moisture -proof, corrosion resistance, wear resistance, and solid durability.

Second, the panel cabinet uses high -quality cold -rolled steel plate bending and seamless welding. The panel cabinet and the mobile table are separated structures for easy disassembly.

Third, the table frame adopts the national standard pipe, seamless welding. The countertop and side plates are bent with high -quality cold -rolled steel plates.

Fourth, the metal surface is treated with high temperature spraying, and the paint surface is strong and beautiful.

【parameter】

Size: (length*width*height) 1450*1000*1650 (mm) Weight: 320kg

【Engine Training Design Training Project】

1. Edar engine work operation demonstration, teaching, and experiment;

2. Signal detection and simulation experiments of each sensor;

3. Electric control system failure settings, exclusion, experiments, training, and assessment;

4. Experiments and training of the engine electro -injection system and decoder communication, settings, fault code signal waveform collection;

5. Disassembling of the electro -injection engine assembly, detection training, etc.
