New Energy Vehicle Drive System Teaching Equipment

Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of new energy vehicle drive system teaching equipment in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.

Product Function

This New Energy Vehicle Drive System Teaching Equipment is built on an authentic pure electric vehicle (EV) drive system, designed to provide a realistic demonstration of the structure and operational process of EV drive systems. Tailored to meet the educational demands of modern automotive training, this equipment is ideal for schools and training institutions focusing on the principles and mechanics of EV technology. It effectively supports curriculum requirements for new energy and energy-saving automotive courses, equipping students with both the theory and hands-on experience needed in today's advancing vehicle industries.

Functional Characteristics

Authentic, Operable EV Drive System: This New Energy Vehicle Drive System Teaching Equipment allows students to fully observe and interact with an actual pure electric vehicle drive system. It delivers a comprehensive display of the internal composition and operational dynamics, providing an exceptional learning platform for understanding modern EV technology.

Durable Training Panel: The equipment features a 4mm thick high-grade aluminum-plastic panel with a superior corrosion-resistant, impact-resistant, fireproof, and moisture-proof finish, making it highly durable for long-term classroom use. The surface is treated with a specialized spray primer, and the panel itself is UV-printed with a vivid color circuit schematic diagram that will not fade over time, allowing students to visualize and trace the drive system components easily.

Integrated EV Instrumentation: The panel includes detailed instrumentation displays, such as power transmission indicators, vehicle speed, voltage, and temperature readouts. These tools allow students to monitor and interpret the various states and changes in the electric drive system in real time. Fault indicator lights for the electric control system further enhance the equipment's utility by displaying immediate feedback on any issues, which reinforces students' diagnostic and troubleshooting skills.

Advanced Signal Detection Terminals: To facilitate accurate diagnostics and testing, this New Energy Vehicle Drive System Teaching Equipment is equipped with detection terminals. These allow for direct measurement of various electrical signals across control unit pins, including resistance, voltage, current, and frequency. This feature enables students to work on real-time data acquisition and analysis, gaining critical insights into the electrical characteristics of each component.

Technical Specifications

Power Supply: High-voltage lithium iron phosphate battery pack, ensuring a stable and safe power source for educational purposes.

Operating Temperature Range: Suitable for a wide range of environments with a robust operating temperature from -40℃ to +50℃, ensuring consistent performance.

Steel Frame: Constructed with a 60mm x 40mm x 3mm steel pipe framework, providing excellent structural integrity and support for the equipment.

Equipment Cabinet: Built with 1.5mm cold-rolled steel plate, precision-stamped for durability and impact resistance.

Mobile Casters: Fitted with durable 100mm x 60mm casters for easy maneuverability and secure positioning within training facilities.

Overall Dimensions: 1740mm (L) x 1200mm (W) x 1700mm (H), making it compact yet fully equipped for in-depth training sessions.

In summary, this New Energy Vehicle Drive System Teaching Equipment serves as an invaluable tool in the automotive educational field. With its focus on real-world application, practical diagnostics, and component testing, it bridges theoretical knowledge with the practical skills required for careers in new energy vehicle technology.
