Automobile Power Windows, Central Control Door Locks And Rearview Mirror System Teaching Board

1. Product introduction:

This training system is based on the real automotive electric window, central control door lock and electric rear view mirror system, and integrates all related control switches and actuators into a teaching board. The system shows the working principle of automotive electric window, central control door lock and electric rear view mirror system.It can perform the demonstration experiment, fault diagnosis, data measurement and other training operations of automobile electric window, central control door lock, electric rear view mirror system.

2. Functional features:

1. Really operable automotive electric window, central control door lock and electric rear view mirror system, fully demonstrating the composition and working process of automotive electric window, central control door lock and electric rear view mirror system.

2. The training platform integrates window motors with four doors, central control door lock motors with four doors, left and right rear-view mirror assembly, window switches, central control lock switches, rear-view mirror switches, etc.

3. The training platform measurement panel is equipped with color spray-drawing circuit diagrams, with detection terminals installed, which can directly detect the electrical signals of each sensor, executor, door control unit pins, such as resistance, voltage, current, frequency signals, etc.

5. The training platform is equipped with a fault setting system, which can set up one or more common faults to simulate the circuit faults of the door system in order to achieve the purpose of examination and assessment.

6. The training platform is equipped with a diagnostic stand, which can connect a dedicated or universal automobile decoder and perform self-diagnostic functions such as reading the fault code, clearing the fault code and reading the data stream for the door system.

3. Materials and processes:

1. The training platform measuring panel is sprayed with 8mm thick high strength acrylic board, which is characterized by large temperature difference resistance, wear resistance, moisture resistance, corrosion resistance, not easy to deform, long service life, bright color, and not easy to fade.

2. The training platform is built with international standard aluminium alloy profile, which has the characteristics of light weight, high strength, corrosion resistance and long service life. It is more environmentally friendly and has a better appearance without spraying process. The platform with self-locking castor wheel device is flexible, safe, reliable and durable.

3. The base of the training platform is made of advanced eco-friendly synthetic wood and aluminum alloy profiles, with two practical and beautiful drawers for daily teaching supplies.

4. The grooves of aluminium alloy profile are covered by PVC tape mosaic, which not only has dust-proof effect, but also outlines the entire training platform, making it more beautiful.

4. Teaching Contents:

1. Cognition of configuration composition of automotive electric window, central control door lock and electric rear view mirror system

2. Understand the control principle of automotive electric window, central control door lock and electric rear view mirror system

3. Master the basic knowledge of automotive electric window, central control door lock, electric rear view mirror system

4. Master the working principle of door system

5. Components capable of independently enumerating and interpreting the door system

6. Master the operating conditions of the door rear view mirror system

7. Independently troubleshoot, maintain and repair the door rear view mirror system

5. Technical parameters:

1. Shape size: 1600×700×1800mm (length×width×height)

2. Input power supply;AC 220V +10%50Hz

3. Working power supply;DC12V
