Trainer Air Brake Training Equipment

Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of Trainer Air Brake Training Equipment in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.

Trainer Air Brake Training Equipment

Technical Specifications
Dimensions: Length 1200–1600mm × Width 1000mm × Height 1700–1800mm (including mobile stand)
Power Supply: External AC 220V ±10% 50Hz; Internal operating voltage DC 12V
Environmental Adaptability: Operating temperature -40°C to +50°C
Structural Design: Welded frame made of 40×40×3mm square tubing; equipped with self-locking swivel casters; load capacity ≥150kg
Panel Material: 4mm thick aluminum-plastic composite panel or 3mm acrylic sheet protecting the circuit diagram; equipped with comprehensive testing terminals
Core Components: Genuine LS400-class ECU, air compressor, high/low-level solenoid valves, front/rear height sensors, damping actuators, diagnostic port
Functional Modules: Supports dynamic height/damping adjustment and self-diagnosis of fault codes; capable of simulating various faults such as open circuits, short circuits, and poor contact (typically 10+ types)
Standard Configuration List (Per Unit)
Testing and control panel (including color schematic and test terminals)
Air suspension ECU (genuine part)
Compressor, height control relay, No. 1 & No. 2 height solenoid valves
Front/rear suspension control actuators and height sensors (sets for both left and right sides)
Diagnostic port, fault indicator light, intelligent fault-setting assessment system
Mobile stand (with self-locking casters), simulated load springs, measuring tools
