Fire Alarm System Training Panel

System overview:

This Fire Alarm System Training Panel is usually used as an independent subsystem of BAS (Building Equipment Management System) in the three major systems of intelligent buildings in intelligent buildings. The system performs fire alarm through the parameter changes of each detection device (smoke detector and temperature detector) in the fire protection system, and realizes the linkage control of fire protection through related signals. The system can carry out various simulated fire and alarm linkage operation demonstrations, system settings, linkage programming, circuit design, networking, circuit and setting fault judgment and elimination and other practical training.

Product Features:

1. The Fire Alarm System Training Kit are connected by terminal blocks, which can form different fire circuits according to the training content;

2. The training device has fire display and linkage functions commonly used in engineering;

3. The system adopts bus structure.

Technical parameters:

1. Working power supply of the training platform: AC220V±10% 50Hz

2. Working environment: the ambient temperature range is -20℃～+45℃ and the relative humidity is less than 85%

3. Dimensions: 1668mm×805mm×1484mm4. Training content1. System equipment recognition and wiring operation

2. Installation and connection of alarm controller, short-circuit isolator and linkage interface module

3. Installation, connection and use of fire display panel

4. Installation and connection of various fire detectors

5. Installation and connection of intelligent input and output modules, sound and light alarms, and alarm buttons

6. Component address coding settings

7. System management operations

8. System data query operation

9. Device start and stop operation

10. Single-point operation

11. Linkage programming

12. Judgment and treatment of line faults

13. Judgment and correction of program setting errors

14. Design and install a simple application system
