Electrical Safety Training Kit electrical troubleshooting training boards

Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of electrical safety training kit electrical troubleshooting training boards in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.

Equipment overview:

The Electrical Safety Training Kit electrical troubleshooting training boards adopts a desktop modular (hanging board) structure with strong scalability. The teaching models are installed on the hanging board, which makes the training components more intuitive and facilitates the students to learn and master.

Equipment Features:

1. Multiple, reliable and comprehensive security protection The main switch of the power supply adopts a reliable leakage protection circuit breaker, which will cut off the power supply within 0.1 seconds in case of leakage of electric energy; secondly, the experimental bench adopts a three-phase five-wire system power supply, and the metal shell of the experimental bench is equipped with special terminals to ensure the reliable grounding of the equipment; The non-touchable experimental socket completely avoids unintentional electric shock.

Perfect hardware configuration:

All kinds of power supplies, instruments, loads, electronic components, circuit modules, etc. required by the training platform are organically combined and fully furnished. The electrical control circuit or electronic circuit components are installed on the mounting plate as the hanging plate, which is easy to operate and replace, and can expand other functions or develop new experiments.

3. The Electrical Safety Training Kit electrical troubleshooting training boards is easy to expand: modular structure, easy to replace the hanging box, easy to organize various training projects, easy to upgrade.

4. Reliability of equipment: components are connected to the terminals, and students plug or wire from the terminals to train students' basic skills of linking theory with practice.

5. Various projects of the electrician training project teaching method can be carried out.

Technical performance:

1. Working power supply: three-phase five-wire, AC380V±10%, 50HZ

2. Power: Pmax is less than 300W

3. Ambient temperature: -30℃-40℃; relative humidity: ≤90%

4. Weight: 80kg

5. Dimensions: 1700mm×750mm×1500mm
