Diesel Engine Training Bench Working Engine Models
Welcome to wholesale high quality Diesel Engine Training Bench Working Engine Models at competitive price from professional Diesel Engine Training Bench Working Engine Models manufacturers and suppliers in China. Contact our factory for quotation and pricelist.
Send Inquiry
Product Introduction
Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of diesel engine training bench working engine models in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.
Core Engine Specifications (Power source for the training stand)
Engine Model: 4JB1-TCT (mainstream turbocharged version for teaching) or 4JB1 (naturally aspirated version)
Displacement: 2.771L (approx. 2.8L)
Cylinder Configuration: Inline-4, water-cooled, OHV (Overhead Valve)
Max. Power: 70kW (95 hp) @ 3400–3600 rpm (TCT version); some older models: 72kW (98 hp)
Max. Torque: 206 N·m @ 1700 rpm (TCT version); mechanical pump version can reach 220 N·m
Fuel System: VE-type mechanical distributor pump (classic teaching model) or electronically controlled high-pressure common rail (new model)
Compression Ratio: 18.5:1
Bore × Stroke: 93mm × 102mm
Emission Standard: Primarily China III/Euro III (common for teaching); some compatible with China IV
Typical Training Stand Technical Specifications
Overall Dimensions: Approx. 1500–1650mm (L) × 1000mm (W) × 1700–1850mm (H)
Power Supply: DC 12V (equipped with 60Ah–90Ah maintenance-free battery)
Fuel Tank Capacity: 10L (stainless steel)
Stand Structure: Powder-coated steel base with self-locking swivel casters; includes protective guards for flywheel, radiator, and drive belts
Display & Testing: Integrated tachometer, water temperature gauge, and oil pressure gauge; equipped with a test terminal block (for measuring voltage, resistance, and signal waveforms) and a color circuit schematic panel
Functional Features: Supports actual starting, idling, and acceleration; fault simulation and troubleshooting; OBD diagnostic port (on some new models)
Application Scenarios: Vocational training in diesel engine structure, fuel system disassembly/assembly, and fault diagnosis
