Common Rail Diesel Engine Trainer Equipment

The tractor co -orbit diesel engine training platform is based on the tractor Bosch 2.8T electrical control high -voltage -rail diesel engine. It can perform the structure and work process of the engine of the engine, accelerating, and deceleration.

Teaching equipment for schools for schools to control high -voltage rail diesel engines and maintenance training for schools require training equipment.

The functional characteristics

1. The real -operated electrical control high -voltage common rail diesel engine (acceleration/deceleration/idle work condition is normal), and fully display the structure and working process of the electronic control high -voltage rail diesel engine.

2. The training table panel adopts high -grade aluminum -plastic panels with 4mm thick corrosion resistance, strike, pollution resistance, fire prevention, and moisture -proof. The surface is sprayed with primer painting by special processes; the panel prints with color circuit diagrams that never fade; students can intuitively intuitively Control circuit diagrams and electronic control high -voltage co -rail diesel engines, understand and analyze the working principle of the control system.

3. The training terminal is installed on the panel, and the electrical signals that can directly detect various sensors, actuators, and engine control units can be detected directly on the panel, such as resistors, voltage, current, frequency signals, etc.

4. Instruments on the training table panel can be installed on the meter, which can display the engine speed, water temperature, oil pressure lamp, charging indicator, and electronic control system fault indicator light in real time.

5. There is a diagnostic seat installation of the training desk, which can be connected to a dedicated or general -purpose car decoder to read the engine electrical control system to read the fault code, clear the fault code, and the data flow.

Technical specifications

Dimensions: 1500 × 1000 × 1700mm (length × width × height)

Work power supply: Original model

Fuel label: according to the engine model

Oil tank volume: 10L

Work temperature: -40 ℃ ~+50 ℃

Color: 7032

Steel pipe: 40*40*3mm

Panel cabinet: 1.5mm cold plate stamping and forming, the repair door is set on the back;

Mobile foot wheel: 120*80mm

Basic configuration (each)
