Intelligent Refrigerator Comprehensive Principle Training Platform

Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of intelligent refrigerator comprehensive principle training platform in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.

PRODUCT OVERVIEW:

This device is a training device specially developed for refrigeration related majors in vocational colleges.

According to the characteristics of refrigeration industry and refrigerator maintenance technology, it is designed for the electrical control of refrigerators and the installation and maintenance of refrigeration systems.

Comprehensive professional ability such as installation of air conditioning and refrigerator system pipelines, electrical wiring, working condition debugging, fault diagnosis and maintenance.

The device integrates technologies such as fluid mechanics, thermodynamics, heat transfer and electrical control, and integrates refrigeration and air conditioning system installation, refrigerator system installation, refrigeration system electrical wiring, pressure leak detection, vacuuming, refrigerant charging and operation and debugging. It can meet the needs of practical training, practical engineering training and vocational skills competition.

TECHNICAL INDICATORS:

*Input powersupply:three-wire AC220V±10% 50Hz

*Working environment: temperature -10℃~-40℃, relative humidity≤85%(25℃)

*Equipment capacity: ≤1.5KVA *Refrigerant: R600a

*Dimensions(approx.):780×500×1250mm

*Type I protection against electric shock

DEVICE FEATURES:

1. The device integrates refrigeration system installation, refrigerator system installation, refrigeration system electrical wiring, pressure leak detection, vacuuming, refrigerant charging, and operation and debugging. The need for practical engineering training and vocational skills competitions.

2. The device adopts a modular design, the electrical controland refrigeration system are separated independently, and the electrical part is equipped with test points, test terminals and output connection terminals of each channel, which can be used by students for independent wiring, testing, long-distance travel and other operations.

3. The training platform visually shows the system structure and working principle of the refrigerator. The structure of the refrigeration system and the physical objects of the main components can be clearly seen. The system is also equipped with a current flow voltmeter, an AC ammeter, a pressure gauge, a signal indicator, etc., so that the real-time working status of the entire air conditioning system and refrigerator system can be seen at a glance.

4.Refrigerator box: It is made of plexiglass to make it transparent,, which can intuitively show the principle of the evaporator, and the temperature can reach-5 degrees.

5. Test bench: aluminum alloy structure, blue on the left and decorative panels and panels,the whole is blue, 6. The equipment has 4 thermometers, which can measurethe main temperature changes of the refrigeration system.
