Pneumatic And Hydraulic Training Bench Plc Training Kit

Guangdong Zhongcai Education Equipment Co.,Ltd. is one of the most reliable manufacturers and suppliers of pneumatic and hydraulic training bench plc training kit in China. Welcome to buy high quality engineering education equipment from our factory. Also, OEM&ODM service is available.

Hydraulic parts

 1. Experimental bench

The experimental bench is composed of aluminum profile main frame, aluminum profile operation panel, electrical cabinet, etc. Workbench size: length×width×height=1500mm×700mm×1850mm (the packing weight is about 220kg), and the aluminum alloy profile structure with "T" groove on the mounting surface

2. Hydraulic pump station Rated working pressure of the system: 0.8 Mpa. Up to 2.5MPa

 (1) Motor-pump device (set) The pump can choose any of gear pump, cycloid pump, vane pump, etc. Motor: DC motor, power 400W, speed 0~1500r/min; speed regulation by DC speed regulator. Built into the experiment table.

 (2) Fuel tank: nominal volume 30L; with liquid level, oil temperature indicator, oil suction and return oil filter, safety valve, etc.

 3. Power supply: With three-phase leakage protection, the output voltage is 380V/220V, the power supply will be cut off when the leakage current to the ground exceeds 30mA; the electrical control adopts DC 24V power supply, and with overvoltage protection to prevent misoperation from damaging the equipment.

 4. Electrical control unit: Programmable controller (PLC); adopts FX1S-20MR, I/O port 20 points; 12 inputs and 8 outputs, relay output form. Power supply voltage: AC 220V/50Hz 5. When the hydraulic pump is working, the noise at a distance of 1.5m from the hydraulic platform is ≤58dB

Feature:

 1. Component modularization: Each pneumatic component is an independent module, equipped with a bottom plate that is easy to install, and various experimental circuits can be set up on the general aluminum alloy profile plate at will, and the operating parts are simple and fast .

 2. Connection mode: The connector adopts quick-type, reliable, simple and time-saving during installation and disassembly.

 3. Pneumatic components: standard industrial pneumatic components, reliable and safe.

 4. System environment: low-noise working pumping station, providing a quiet experimental environment (noise <60). Pump station with automatic overpressure protection device

 5. Control diversification: PLC programming control, relay manual control, time relay control automatic control
